DESCRIPTION

Basic Info.

Model NO.	HUANBALL-2022
Service	OEM Supporting
Usage	Transmission Chain, Transpor
Certificate	ISO
MOQ	100PCS
Material Feature	Good Flexibility, Non-Slipping, Durability, Heat R
Size	Customized
Structure	PU,Rubber,Fiberglass Cord,Nylon Elastic Fabric,.Et
Color	Solid Color
Toothed Type	Arc Toothed, Trapezoidal Toothed,T-Toothed,S-Tooth
Name	Timing Belt
Transport Package	Carton
Specification	Complete
Trademark	Huanball
Origin	Zhejiang
Production Capacity	1000000

Product Description

Product name:	Timing belt
Teeth profile:	Arc toothed:HTD3M, HTD5M, HTD8M, HTD14M, HTD20M
	Arc Gt toothed:Gt2,Gt3,Gt5,
	Trapezoidal toothed:MXL, XXL, XL, L, H, XH, XXH
	T-toothed: T2.5, T5, T10, T20
	AT-toothed:AT3,AT5,AT10,AT20
	S-toothed:S2M, S3M, S4.5M, S5M, S8M, S14M
	Parabolic-toothed:P2M, P3M, P5M, P8M, P14M
	Y-toothed:G2M, G3M, G5M, Y8M
customize:	logo,color,size,Hardness etc
material:	PU,Rubber,fiberglass cord,nylon elastic fabric,.etc
Colors:	White, Black, Green, Brown, Blue, Red, Yellow, ETC
Feature:	Good Flexibility, Non-slipping, Durability, Heat resistant, Anti-static, long service life

trapezoidal toothed synchronous belt	TYPE	Pitch	Booth adge	Bottom tooth thickness	Tooth height	Fillet	Tip	Belt thickness	teeth number range	Pitch length
		Pb	2y°	s	hg	rr	ra	H
	MXL	2.023	40	1.14	0.51	0.13	0.13	1.14	43~2044	87.38~4153.41
	XXL	3.175	50	1.73	0.76	0.20	0.20	1.52	46~124	146.05~393.70
	XL	5.085		2.57	1.27	0.38	0.38	2.3	22~510	111.76~2590.80
	L	9.525	40	4.65	1.91	0.51	0.51	3.6	23~530	219.08~5048.25
	H	12.700		6.12	2.29	1.02	1.02	4.3	29~440	368.30~5588.00
	XH	22.225		12.57	6.35	1.57	1.57	11.2	53~220	1177.93~4889.50
	XXH	31.750		19.05	9.53	2.29	2.29	15.7	56~144	1778.00~4572.00

T-toothed synchronous belt	TYPE	Pitch	Booth adge	Bottom tooth thickness	Tooth height	Fillet	Tip	Belt thickness	teeth number range	Pitch length
		Pb	2y°	s	hg	rr	ra	H
	T2.5	2.5	40	1.50	0.70	0.2	0.2	1.3	42~312	105.00~780.00
	T5	5		2.65	1.20	0.4	0.4	2.2	30~400	150.00~2000.00
	T10	10		5.30	2.50	0.6	0.6	4.5	34~536	340.00~5360.00
	T20	20		10.15	5.00	0.8	0.8	8.0	61~181	1220.00~3620.00

Arc synchronous belt	TYPE	Pitch	Booth adge	Bottom tooth thickness	Tooth height	Fillet	Tip	Belt thickness	teeth number range	Pitch length
		Pb	2y°	s	hg	rr	ra	H
	3M	3	14	1.78	1.17	0.24-0.30	0.87	2.4	35~1000	105.00~3000.00
	5M	5		3.05	2.06	0.40-0.44	1.49	3.8	35~852	175.00~4260.00
	8M	8		5.15	3.36	0.64-0.76	2.46	6.0	36~565	288.00~4520.00
	14M	14		9.40	6.02	1.20-1.35	4.50	10.0	56~340	784.00~4760.00
	20M	20		14.00	8.40	1.77-2.01	6.50	13.20	100~260	2000.00~5200.00

S-toothed synchronous belt	TYPE	Pitch	Bottom tooth thickness	Tooth height	Fillet radius	Fillet	Tip	Belt thickness	teeth number range	Pitch length
		Pb	s	hg	rbb	rr	ra	H
	S2M	2	1.3	0.76	1.3	0.20	0.20	1.36	44~1914	88.00~3828.00
	S3M	3	1.95	1.14	1.95	0.30	0.30	1.94	41~500	123.00~1500.00
	S4.5M	4.5	2.93	1.71	2.93	0.45	0.45	2.81	40~201	180.00~904.50
	S5M	5	3.25	1.91	3.25	0.50	0.50	3.41	30~560	150.00~2800.00
	S8M	8	5.20	3.05	5.20	0.80	0.80	5.30	53~500	424.00~4000.00
	S14M	14	9.10	5.30	9.10	1.40	1.40	10.2	69~322	966.00~4508.00

Parabolic synchronous belt	TYPE	Pitch	Bottom tooth thickness	Tooth height	Belt thickness	teeth number range	Pitch length
		Pb	s	hg	H
	P2M	2	1.30	0.73	1.3	56~612	112.00~1224.00
	P3M	3	1.95	1.09	2.1	30~621	90.00~1863.00
	P5M	5	3.25	1.81	3.6	36~400	180.00~2000.00
	P8M	8	5.20	2.90	5.5	40~550	320.00~4400.00
	P14M	14	9.50	6.00	10.0	69~327	966.00~4578.00

G.Y-toothed synchronous belt	TYPE	Pitch	Tooth height	Fillet radius	Fillet	Tip		Belt thickness	teeth number range	Pitch length
		Pb	hg	r1	r2	r3	b	H
	G2M	2.0	0.75	0.15	1.00	0.555	0.75	1.38	56~612	112.00~1224.00
	G3M	3.0	1.14	0.25	1.52	0.85	1.14	2.40	30~621	90.00~1863.00
	G5M	5.0	1.93	0.51	2.54	1.37	1.03	3.80	36~400	180.00~2000.00
	Y8M	8.0	3.02	1.08	3.80	2.10	1.43	5.00	40~550	320.00~4400.00

Ningbo Huanball Rubber & Plastic Co.,Ltd
Ningbo Huanball Rubber & Plastic Co.,Ltd Established in 2008, Is a Specializing in the production of agricultural/industrial machinery parts, currently producing timing belts, conveyor belts, crawlers, synchronous wheels, gears, bearings, engines and other spare parts. Our products are SGS, RoHS, M1 and UL certified,Our factory is located in Zhangting Industrial Zone, Yingzhou, Ningbo, which is only 50 kilometers away from the famous Ningbo Port (Harbor). covers an area of 9,000 square meters, with 6,000 square meters' standard workshops and world-class equipment. we have exported our products to many international markets including the UK, Southeast Asia, France, Australia, Canada, etc.Please feel free to contact us for more information.

==================================== FAQ ======================================
1) Q: I haven't done business with you before, how can i trust your company?
A: Our company are made-in-china golden supplier and passed Field certification by made-in-china. What's more,we've got authority certificates for ISO9001.
2) Q: How is quality ensured?
A: All our processes strictly adhere to ISO9001:2008 procedures, we have strict quality control from producing to delivery,100% inspection by professional testing centre. Small samples could be provided to you for testing.
3) Q: Can i get 1 or more samples?
A: Yes, sample orders welcomed.
4) Q: Do you give any discounts?
A: Yes, we'll surely try my best to help you get the best price and best service at the same time.
5) Q: How to Custom-made(OEM/ODM)?
A: Please send you product drawings or samples to us if you have, and we can custom-made as you requirements.We will also provide professional advices of the products to make the design to be maximize the performance.
